Description:
Measure -50 to 500°C with this stainless steel class B PT1000 RTD probe. As an RTD this probe offers excellent accuracy and very low drift in comparison to what a thermocouple can offer.
Note: Beyond the 11cm tip, this RTD is not waterproof. Shipping from approx. February 25th 2022.
Connection
This RTD connects to an RTD interface. See the Connection & Compatibility tab for details.
Product Specifications
| Sensor Properties | |
|---|---|
| Sensor Type | RTD |
| Temperature Sensor | |
| Ambient Temperature Min | -50 °C |
| Ambient Temperature Max | 500 °C |
| Class B RTD Temperature Error Max | ±(0.30 + 0.005* t) °C† |
| Physical Properties | |
| Cable Length | 1 m |
| Probe Diameter | 3.2 mm |
| Cable Diameter | 3 mm |
| Probe Material | Stainless Steel |
†Where t is the measured temperature (without respect to sign).
This PT1000 RTD can be read by connecting it to any of the RTD interfaces in the list below.
|
 |
PT1000 4-Wire RTD 11cm
- Brand: Phidgets
- Product Code: TMP4109_0
- Availability: In Stock
-
59.75€
- Ex Tax: 49.38€
